QUINT-UPS/ 24DC/ 24DC/40
11.6
Setting the buffer time
You can set the time for exiting battery mode via the selection
switch on the front of the device.
t max [min] setting
1, 2, 3, 5, 10, 15, 20
Custom (default 0.5)
? (unlimited, delivery state)
PC mode
Meaning
The UPS switches off after the set buffer time.
The UPS switches off after the individual buffer time set via UPS-CONF.
Buffering with the total stored power. A warning is generated as soon as the power storage
device only has 10 ? % charge (default).
In PC mode, it is possible to continue working with a PC after a mains failure, perform a con-
trolled shutdown and restart automatically.
11.7
PC mode
In "PC mode", the UPS function follows a chronological se-
quence that can be parameterized via the software and indi-
vidually optimized for the relevant application.
In the event of a mains failure, PC can continue to work, per-
form a controlled shutdown and restart automatically.
It is required that the following is installed:
IFS-USB-DATACABLE data cable (Order No.
2320500)
UPS-CONF software (Order No. 2320403,
available free of charge at
www.phoenixcontact.net/catalog )
Communication cable between the UPS and
the power storage device
104660_en_01
PHOENIX CONTACT
23
